A05-Heavy Duty Spiral Cutterhead
Application / Machine
Planing,surfacing and four-side moulder.
Workpiece material
Solid wood.
Technical information
You can choose the knife with shear angle or straight angle,shear angle is the angle between knife angle and the center line of cutterhead,it provide Single-point cutting.
Quiet cutting minimum tearing and lower power requirement.
| Item NO. | D (mm) | B (mm) | H (mm) | T |
|---|---|---|---|---|
| A0510008 | 100 | 30 / 35 | 80 | 6 |
| A0510010 | 100 | 30 / 35 | 100 | 6 |
| A0510013 | 100 | 30 / 35 | 130 | 6 |
| A0510015 | 100 | 30 / 35 | 150 | 6 |
| A0510018 | 100 | 30 / 35 | 180 | 6 |
| A0512508 | 125 | 40 / 50 | 80 | 6 / 8 |
| A0514008 | 140 | 40 / 50 | 80 | 6 / 8 / 10 / 12 |
| A0512510 | 125 | 40 / 50 | 100 | 6 / 8 |
| A0514010 | 140 | 40 / 50 | 100 | 6 / 8 / 10 / 12 |
| A0512513 | 125 | 40 / 50 | 130 | 6 / 8 |
| A0514013 | 140 | 40 / 50 | 130 | 6 / 8 / 10 / 12 |
| A0512515 | 125 | 40 / 50 | 150 | 6 / 8 |
| A0514015 | 140 | 40 / 50 | 150 | 6 / 8 / 10 / 12 |
| A0512518 | 125 | 40 / 50 | 180 | 6 / 8 |
| A0514018 | 140 | 40 / 50 | 180 | 6 / 8 / 10 / 12 |
| A0512520 | 125 | 40 / 50 | 200 | 6 / 8 |
| A0514020 | 140 | 40 / 50 | 200 | 6 / 8 / 10 / 12 |
| A0512523 | 125 | 40 / 50 | 230 | 6 / 8 |
| A0514023 | 140 | 40 / 50 | 230 | 6 / 8 / 10 / 12 |
